EFS – Electrical Flow Simulation
Voltage, Current and Energy Flow in DC Networks
Typical questions
Substations switch of. Why?
New traction vehicles. Energy usage?
Are energy savings possible?
Would an energy storage pay for itself?
Time table changes. Can the required energy be supplied?
Extending the network. How many substations are required?
The goal is to
calculate the energy usage
identify weak parts of the network
help finding solutions for the weak parts
analyse the benefits of investments
find optimal solutions
All of this can be done by yourself
using our software
What is EFS?
Dynamic mathematical model of your specific DC network
Taking in account all electrical components
Calculates the energy flow in the network
Easy to use
Delivers reliable results
Easy to maintain
A sustainable investment
Of what use is EFS?
Identifies critical substations
Calculates the degree of load on each substation
Displays current and voltage flow in the overhead contact
system
Shows energy usage of traction vehicles
Points out energy losses in the network
