S30 X/C is electronically controlled, driven by 3 pcs of 12 V batteries which is easily exchangeable with a cassette system.
All Safetrack equipment comes with the well reputated, easy to use, automatic (no setting required) S4 brazing gun (patent) and the constant energy electronic that ensure that correct energy is delivered in every brazing, no matter which level of battery voltage. Patent.
This equipment saves a lot of cost since it use brazing pins without fusewire which cost less and one do have no "waste" of misfired brazing pins that the old type with fusewires have.
SAFE 9308CP is Delivered with:
- Brazing gun S4 Automatic SAFE 9102
(The gun is delivered with a mounted Pin Holder (A) SAFE 9211 and Ring Holder 9202.)
- Battery Box SAFE 93211300 (box incl. 3 x 13Ah batteries SAFE 8092)
- Battery Charger 36V/7A-100/240V, SAFE 8049
- Ground magnetic, 2,7m OnOff SAFE 80730
- Accessory Case SAFE 95240
- Shoulder strap SAFE 9523
- Protective eyewear SAFE 8043
- Grinding stone SAFE 8025
- Carbide burr SAFE 8014
Technical Specification:
- Voltage: 36 V DC
- Number of Brazings per charge: 40
- Weight (with 13Ah batteries): 22 kg
- Dimensions: Width 230 mm Height 390 mm Length 280 mm
Accessories:
- Grinding machine BGD800 Makita SAFE 593070
- Battery Charger 7A SAFE 8049
- Battery charger, b. car use SAFE 8055
- High power batteries 13 AH SAFE 8092
- High power batteries 16 AH SAFE 8093
- Ground w.super magnetic f.CP SAFE 8069
- Ground Grip SAFE 8071
- Grinding wheel, silicone free SAFE 8025
- Carbide burr, Type C SAFE 8014
- Carbide burr, Type C extended SAFE 8014XL
- Handy 2-rail trolley SAFE 9361
- Separate battery box f.16Ah SAFE 9320 exl. batteries. With lid and handle.
- Separate battery box f.13Ah SAFE 9321 exl. batteries. With lid and handle.
- Battery adapter for charging SAFE 9318 Of Separate battery box
- Angle Device for S4 gun SAFE 9232
- Pin Holder 8-9.5 (A) SAFE 9211
- Pin Holder M8 (B) SAFE 9213
- Pin holder M10 (C) SAFE 9215
- Pin holder M12 (D) SAFE 9217
- Ring Holder 8 to 9.5 SAFE 9202
- Ring Holder M8/M10/M12 SAFE 9204
- Extension Set for S4 / 8 to 9.5 SAFE 9227
- Extension Sets threaded pin SAFE 9229
