Features:
Light weight, compact and slim design
Accepts BEKU type dies
Yoke and Latch type head for easy die changes and removal of connectors
Adjustable ram stroke, 10-15 mm to minimize pumping action
Built-in bypass relief valve
Small handle spread for close quarter applications
Specifications:
Length: 375 (L)mm
Weight: 2.4 kgs
Max. Pressure: 550 bar
Oil Required: 56 cc
Max. Output: 52 kN
Benefits:
- Light weight, compact and slim design
- Yoke and Latch type head for easy die changeover and easy removal of jointed conductor
- Small handle spread
- Built-in bypass relief valve
