Effective ranges (for gauge 1435 mm):
Track gauge: 1415 - 1475 mm
Check rail gauge: 1385 - 1405 mm
Back-to-back distance: 1344 - 1361 mm
Flangeway clearance: 30 - 83 mm
Cant: -30 to +200 mm
Dimension and weight:
Length x Width x Height: 1618 x 100 x 165 mm
Weight: 2,5 kg
Special features
The measuring device is insulated and officially approved by DB.
Note
RCA is available for other track gauges, too
(i.E. 1000 mm, 1524 mm, 1668 mm).
